Products

OEM Friendly Access Control Devices

Integration-ready, installer-friendly, and prepared to meet all current and future physical security requirements. All hardware is UL/ULC, CE, and FCC certified and have industry-leading MTBF ratings. Most of our products have the same dimensions and mounting as Mercury Security panels allowing for drop-in replacement, using existing wiring and enclosures.

BLU-IC4

Qries

  • 4-Door Controller with interfaces to completely secure 4 Access Points
  • * 4 Wiegand Reader Ports
  • * 16 Supervised Inputs
  • * 8 Relay Outputs
  • * 2 Downstream RS485 Serial Ports for OSDP Readers as well as IO and Reader Interface panels
  • * 2 Dedicated Ethernet Ports
  • * USB 2.0
  • * Onboard power monitoring with memory and RTC backup
  • Read more

BLU-IC2

Qries

  • 2-Door Controller with interfaces to completely secure 2 Access Points
  • * 2 Reader Ports that can support Wiegand and RS485 (OSDP) readers
  • * 8 Supervised Inputs
  • * 4 Relay Outputs
  • * 2 Downstream RS485 Serial Ports for IO and Reader Interface panels
  • * 1 Dedicated Ethernet Port
  • * USB 2.0 (Micro-AB connector)
  • * Micro SD memory card
  • * Onboard power monitoring with memory and RTC backup
  • * PoE+ (Power over Ethernet)
  • Read more

BLU-IO168

Qries

  • Downstream Input/Output Interface
  • * Elevator control
  • * 16 Supervised Inputs
  • * 8 Relay Outputs
  • * 1 RS485 Serial Port
  • * 1 Dedicated Ethernet Port
  • * PoE+ (Power over Ethernet)
  • Read more

BLU-RI2M

Qries

  • 2-Reader Downstream Interface to completely secure 2 Access Points
  • * 2 Reader Ports that can support Wiegand and RS485 (OSDP) readers
  • * 6 Supervised Inputs
  • * 4 Relay Outputs
  • * 1 Upstream RS485 Port
  • * 1 Dedicated Ethernet Port
  • * PoE+ (Power over Ethernet)
  • Read more

BLU-RI4

Qries

  • 4-Reader Downstream Interface to completely secure 4 Access Points
  • * 4 Reader Ports that can support Wiegand and RS485 (OSDP) readers
  • * 12 Supervised Inputs
  • * 8 Relay Outputs
  • * 1 Upstream RS485 Port
  • * 1 Dedicated Ethernet Port
  • Read more

BLU-IO21

Qries

  • 1-Door Downstream Input/Output Interface
  • * 2 Supervised Inputs
  • * 1 Relay Output
  • * 1 Upstream RS485 Port
  • * Custom enclosure with tamper sensor
  • * Install on same power and OSDP serial bus as OSDP readers
  • Read more

BLU-XO8

Qries

  • + 8 Relay Expansion Module
  • * Mounts to BLU-IO168 & BLU-O8 to add 8 relays
  • * Powered from IO baseboard
  • * LED indicators for relay status
  • Read more
